PCB Assembly Capabilities

HXD provides reliable PCB assembly services for prototypes and mass production. We support different board types, component packages, and assembly needs with stable quality and fast delivery.

The table below lists our standard PCB assembly capability parameters. If your assembly requirements fall outside these ranges, please email us at sales@hxdcircuit.com. Our engineering team will review your requirements and respond within 12 hours.

Technical Specs

PCB Assembly Specifications

Review HXD's PCB assembly specifications, including supported PCB types, component packages, production capabilities, and quality standards.

Capability	Specification
Assembly Types	SMT, THT, Mixed Technology
Assembly Sides	Single- and Double-Sided
Component Size	Passive Components: We can assemble passive components as small as 01005, including 0201 and 0402 packages. BGA Assembly: We support BGA pitch down to 0.3 mm on rigid PCBs and 0.4 mm on flexible PCBs, with X-ray inspection available. Final capability depends on the board design. Fine-Pitch Components: We can assemble fine-pitch components with a pitch as small as 0.25 mm.
Supported Packages	BGA, QFN, QFP, CSP, SOIC
Maximum PCB Size	250mm x 500mm
PCB Types	Rigid, Flex, Rigid-Flex, Metal Core
Solder Types	Lead-Free (RoHS), Leaded
Soldering Methods	Reflow, Wave, Selective, Manual
Component Packaging	Reel, Cut Tape, Tray, Tube, Bulk
Production Volume	Prototype, Low Volume, Mass Production
Standards	IPC-A-610 Class 2 / Class 3

Get a Quote

Send your Bom for Engineering Review

Share your BOM, target quantity,and required delivery date. Our team will review availability,sourcing risks, and alternatives.

Request a PCB Assembly Quote

Testing & Quality Control

We use different testing and inspection methods to find problems before shipment. Additional testing can be reviewed according to your product and test requirements.

Visual Inspection: Checks the overall assembly quality, including solder joints, component placement, and visible defects.
In-Line AOI: Checks solder paste, small components such as 0201 parts, missing components, component position, and polarity.
3D BGA X-Ray Inspection: Checks hidden solder joints under BGA and QFN components to find voids, bridges, open joints, and other defects.
Flying Probe Testing: Checks the electrical connections on the assembled PCB to find open circuits, short circuits, and incorrect component values.
Functional Testing: Tests the assembled PCB based on your test procedures.
If your PCB assembly requirements fall outside the capabilities listed above, please contact HXD and send your design files for an engineering review.

Certifications and Industry Standards

Our PCBA factories follow strict quality standards to make sure every assembled board meets your requirements.

ISO 9001 Certified Quality System
IPC-A-610 Class 2/3 Standard
First Pass Yield ≥ 99.5%
Quality Complaint Rate ≤ 0.1%

HXD uses complete PCB assembly capabilities, reliable testing equipment, and experienced engineers to provide a one-stop PCBA solution from prototypes to mass production.

FAQ

Frequently Asked Questions About PCB Assembly Capabilities

What PCB assembly services does HXD provide?

HXD provides PCB fabrication, component sourcing, SMT assembly, through-hole assembly, inspection, testing, and final delivery. Full turnkey, partial turnkey, and kitted assembly options are available.

What PCB assembly technologies does HXD support?

HXD supports SMT, through-hole, and mixed-technology assembly for single-sided and double-sided circuit boards.

What is the smallest passive component HXD can assemble?

HXD can assemble passive components as small as 01005, including commonly used 0201 and 0402 packages. Final capability is confirmed after reviewing the PCB design.

What is the minimum fine pitch supported by HXD?

HXD can assemble fine-pitch components with a pitch as small as 0.25 mm. Pad design, component package, board finish, and component spacing will be checked before production.

What component supply options are available?

HXD offers full turnkey, partial turnkey, and kitted or consigned assembly. HXD can source all components, source selected components, or assemble components supplied by the customer. Any component substitutions must be approved before use.

What files are required for a PCB assembly quotation?

Please provide the Gerber files, BOM, pick-and-place file, and assembly drawing. You should also include polarity markings, special assembly instructions, firmware files, and testing requirements when applicable.
